# List Manipulation

In this article, we will discuss how to process the List in Lisp. As you may be well aware, LISP stands for “List Processing”.

A list is a group of elements consisting of any data type and is stored as a single variable. A list can contain any number of Reals, Integers, Strings, Variables and even other Lists. Let’s have a look at a list. Type this :

(setq pt1 (getpoint “\nChoose a Point : “))

AutoLisp should return something like this : (127.34 35.23 0.0)

Now what do I do with the list? AutoLisp has many functions available to manipulate lists. Let’s take a look at them.

Car

The primary command for taking a list apart is the “Car” function. This function returns the first element of a list. (The x coordinate.)

For example :

(setq a (car pt1))

Would return : (127.34)

Cdr

This function returns the second element plus the remaining elements of a list.

For example :

(setq b (cdr pt1))

Would return : (35.23 0.0)

But what if we only wanted the second element? We could write :

(setq b (car (cdr pt1)))

There is a better way to do this task. AutoLisp provides the “Cadr” function which is basically an abbreviation of a nested command.

This returns the second element of a list. (The y coordinate.)

This would return : (35.23)

Likewise, there is another abbreviated function to return the third element.

This returns the third element of a list. (The z coordinate.)

Would return: (0.0)

AutoLisp has other functions that will retrieve values from lists of more than three elements. (Caar, cadar, etc). You can also use the nth function to access any element of a list.

nth

The syntax for the nth function is as follows : (nth num list)

“num” is the number of the element to return. Just remember that zero is the first element. For example given the list :

(setq d ‘(“M10” “M20” “M30” 10.25))
(setq e (nth 0 d))

Would return : (“M10”)

And likewise : (setq f (nth 3 d))

Would return : (10.25)

We have now managed to extract elements from a list, but what do you do if you want to create a new list ? Let’s say you have two elements :

(setq a 200.0)
(setq b 400.0)

You want to combine them to create a new list. To do this you would use the “List” function. For example :

(setq c (list a b))

Would return : (200.0 400.0)

You could also write the function like this: (setq c ‘(a b))

Here is an example of List Manipulation. We are going to use the (car), (cadr) and (list) function to draw a rectangle.

(defun c:rec ( / pt1 pt2 pt3 pt4)
(setq pt1 (getpoint “\nSelect First Corner: “))
;get the first point
(setq pt3 (getcorner pt1 “\nSelect Second Corner: “))
;get the third point
(setq pt2 (list (car pt1) (cadr pt3)))
;construct the second point
(setq pt4 (list (car pt3) (cadr pt1)))
;construct the fourth point
(command “Line” pt1 pt2 pt3 pt4 “c”)
;draw the rectangle
(princ)
);defun

Let’s look closer at the line :

(setq pt2 (list (car pt1) (cadr pt3)))

This function retrieves the first element (x coordinate) from the list pt1, the second element (y coordinate) from the list pt3, creates a list from these elements and stores the list in the variable pt2.

AutoLisp provides other functions to manipulate lists. Let’s take a look at some of them.

Last

Will return the last element of a list :

(last ‘(“M20” “M24” “M30”))

Would return : (“M30”)

Length

This returns an integer indicating the number of elements in a list :

(length ‘(“M20” “M24” “M30”))

Should return :(3)

Member

This function searches a list for a specific element. If found it returns the element plus the remainder of the list :

(member ‘c ‘(a b c d e f))

Would return :(c d e f)

Reverse

Returns a list with it’s elements reversed :

(reverse ‘(a b c d e f))

Will Return :(f e d c b a)

Subst

Searches a list for an old element and returns a copy of the list with the new item substituted in place of every occurrence of the old item :

Syntax: (subst newitem olditem lst)

(subst ‘f ‘c lst)

Would return (a b f d e f)
